254PBG 404420 F - Glycodur United Kingdom Sales

BRAND	Glycodur
Product	254PBG 404420 F
Internal code	549273
Weight	1
Custom code	8483308
Technical specification	GLYCODUR collar Product number: 254PBG 404420 F GLYCODUR® F bearings have a copper-plated steel support on which a 0.2 to 0.4 mm thick, porous tin-bronze layer is sintered. In a rolling process, the pores of this layer are filled with polytetrafluoroethylene (PTFE), which is mixed with additives that reduce friction and wear. A 5 to 30 μm thick top layer of the same material forms the run-in layer. GLYCODUR® F bearings optimally combine the good mechanical properties of sintered bronze with the good sliding and lubricating properties of a PTFE compound. The material structure ensures good dimensional accuracy and thermal conductivity. Maximum gliding speed: 2 m/s Friction coefficient: 0.03 to 0.25 microns Wear layer thickness: 0.2 mm Edge load capacity: less good AC load capacity: good Embedding dirt and foreign objects: less good Usability for longitudinal movements: less good Inner diameter d40 mm external diameter D44 mm Bund yes/no SeriesPBG Static load ratings 160 kN Temperature range from/to -200 to +260 °C Waistband width B12 mm ECLASS 7.123-05-01-01 (dry slurry bearing) PFTE coating Width B20 mm Type flange socket MaterialSteel No maintenance requirement Dynamic load ratings 51.2 kN Waist height D153 mm Manufacturer colorsilver/grey

Please Contact Us to Order to offer competitive prices and delivery time for Glycodur - 254PBG 404420 F number, also you may ask some other model number is well. We can offer competitive price, and delivery time with wide products distribution network in United Kingdom Industrial products Market.
