| BRAND | Ifm |
| Product | PC3542 |
| Description | Pressure transmitter |
| Internal code | 1120017 |
| Weight | 1 |
| Technical specification | PT-100-SBG14-A-ZVG/US/ /W, Origin: DEUTSCHLAND, Custom Tariff No. 90262020, Weight in KG: 0,079 Product characteristics Number of inputs and outputs Number of analog outputs: 1 Measuring range [bar] 0...100 Process connection threaded connection G 1/4 external thread Application Application for industrial applications Media liquids and gases Medium temperature [°C] -25...90 Min. bursting pressure [bar] 1000 Pressure rating [bar] 200 Type of pressure relative pressure Electrical data Operating voltage [V] 8.5...36 DC Min. insulation resistance [MΩ] 100; (500 V DC) Protection class III Reverse polarity protection yes Inputs / outputs Number of inputs and outputs Number of analog outputs: 1 Outputs Total number of outputs 1 Output signal analog signal Number of analog outputs 1 Analog current output [mA] 4...20 Max. load [Ω] 775; (Ub = 24 V; (Ub - 8,5 V) / 20 mA) Measuring/setting range Measuring range [bar] 0...100 Accuracy / deviations Repeatability [% of the span] < ± 0,1; (with temperature fluctuations < 10 K) Characteristics deviation [% of the span] < ± 1,0; (incl. drift due to tightening torque, zero and span error) Linearity deviation [% of the span] < ± 0,25 (BFSL) / < ± 0,5 (LS) Hysteresis deviation [% of the span] < ± 0,2 Long-term stability [% of the span] < ± 0,1; (per 6 months) Temperature coefficient zero point [% of the span / 10 K] < ± 0,1; (-25...90 °C) Temperature coefficient span [% of the span / 10 K] < ± 0,1; (-25...90 °C) |
Please Contact Us to Order to offer competitive prices and delivery time for Ifm - PC3542 Pressure transmitter number, also you may ask some other model number is well. We can offer competitive price, and delivery time with wide products distribution network in United Kingdom Industrial products Market.
WE SELL ONLY NEW AND ORIGINAL PRODUCTS!
Our company is not an authorized distributor. All rights are reserved by the manufacturers and their official partners.
