BRAND | Elettrotec |
Product | PMN10ABN18K (pack of 10) |
Description | Pressure switch |
Internal code | 4360806 |
Custom code | 903220000 |
Technical specification | Z710-00489-99999-10 1/8" BSPT pressure switch (diaphragm) - NO contact (brown connection) Adjustment: screw between contacts Setting range: 2 - 10bar Connection thread: G1/8" BSPT Material: brass seal: NBR max. static pressure: 300bar max. ohmic load: 0.5 A at 48VDC temperature range ፦5°C - 60°C Switching cycles: 200rpm hysteresis at 25°C: 0.2 bar tolerance at 25°C: ± 0.3 bar Lifespan: 1,000,000 cycles Available certificates: available certificates: cURus, UL |
Please Contact Us to Order to offer competitive prices and delivery time for Elettrotec - PMN10ABN18K (pack of 10) Pressure switch number, also you may ask some other model number is well. We can offer competitive price, and delivery time with wide products distribution network in United Kingdom Industrial products Market.
WE SELL ONLY NEW AND ORIGINAL PRODUCTS!
Our company is not an authorized distributor. All rights are reserved by the manufacturers and their official partners.
