BRAND | Elettrotec |
Product | PSM10BNR14 |
Description | pressure switch |
Internal code | 4132922 |
Custom code | 90268020 |
Technical specification | 710-325-01050 pressure switch 1 - 10bar (300bar) changeover contact - AG-1/4 PSM10BNR14 pressure switch (diaphragm) - changer incl. die plug Switching point adjustment: central screw between contacts Hysteresis adjustment: screw between pin 2 and pin T Setting range: 1 - 10bar Connection thread: G1/4" Material: brass seal: NBR max. static pressure: 300bar max. ohmic load: 6A at 250VAC temperature range ፦5°C - 90°C Switching cycles: 120/min Hysteresis: adjustable 10 - 30% tolerance at 25°C: ± 0.4bar Lifespan: 1,000,000 cycles |
Please Contact Us to Order to offer competitive prices and delivery time for Elettrotec - PSM10BNR14 pressure switch number, also you may ask some other model number is well. We can offer competitive price, and delivery time with wide products distribution network in United Kingdom Industrial products Market.
WE SELL ONLY NEW AND ORIGINAL PRODUCTS!
Our company is not an authorized distributor. All rights are reserved by the manufacturers and their official partners.
