Typ MDR 3/11 EA EV 3S R 3/10 (MDR 3/11-10) Condor

Typ MDR 3/11 EA EV 3S R 3/10 (MDR 3/11-10) - Condor United Kingdom Sales

BRAND	Condor
Product	Typ MDR 3/11 EA EV 3S R 3/10 (MDR 3/11-10)
Description	pressure switch
Internal code	3309813
Weight	0.65
Technical specification	connector F4 G1/2 103048 Description: •three-phase current version •Breaking capacity 7.5 (11) kW/20 HP •available with overcurrent relay •max. switch-off pressure 35 bar •3-pin (normally closed) •acc. to EN 60947 •Flange material=aluminum die casting Technical data (DIN EN 60947-4-1): Rated operational power (AC 3) Ue =250 V (1~)/400 V (3~)/500 V (3~) :5.5 kW/ 7.5 kW/7.5 kW rated frequency 50 Hz measurement insulation voltage Ui 690 V conditional rated short-circuit current (Ue = 500 V) 50 kA Rated Surge Withstanding Voltage (Uimp) 6 kV Degree of pollution 3 protection class I Mechanical life switching cycles > 1 X 106 Max. switching frequency mechanical switching cycles/ h 600 Contact life (AC 3) Switching cycles > 1 X 105 Rated mode (class 120) switching cycles/h 120 temperature range -5°C to +80°C Protection class IP 54 Silberleg contact material

Please Contact Us to Order to offer competitive prices and delivery time for Condor - Typ MDR 3/11 EA EV 3S R 3/10 (MDR 3/11-10) pressure switch number, also you may ask some other model number is well. We can offer competitive price, and delivery time with wide products distribution network in United Kingdom Industrial products Market.

WE SELL ONLY NEW AND ORIGINAL PRODUCTS!

Our company is not an authorized distributor. All rights are reserved by the manufacturers and their official partners.
