R120-04FK07_01 - Aircom United Kingdom Sales

BRAND	Aircom
Product	R120-04FK07_01
Description	pressure regulator
Internal code	4603517
Custom code	84811099
Technical specification	Connection thread: G1/2 Connection: G1/2 inlet pressure max. [bar]: 50 Control range [bar]: 2... 30 Air flow rate [Nl/min]: 2080 Kv [m³/h]: 3.0 Control system: K All other technical data can be found in the description text. Description: Robust pressure regulator made entirely of brass or bronze. The R120-0.A to -0.E and R120-16 and -32 versions have Control system one diaphragm, all others have a piston. Medium: Compressed air, neutral gases or liquids inlet pressure: see table, max. 50 bar for liquids, differential pressure max. = 25 bar Adjustment: - with adjusting screw for R120-01/-A2 - with black rotary knob for R120-02 - with toggle for R120-04 to -B6 - with hexagonal SW 24 mm for R120-16 - with pilot pressure regulator for R120-24/-32 Rewind: - reversible (secondary ventilation) up to R120-B6 - not reversible for R120-16/-24/-32 Pressure gauge connection: G1/8 on both sides for R120-01/-A2, all other G1/4 on both sides, 1 screw plug is included Installation position: arbitrary Temperature range: 0 °C to 80 °C, with suitably treated compressed air down to -20 °C, or low temperature version down to -40 °C, optional high-temperature version up to 130 °C Case: - brass O-rings: FKM, optionally EPDM feather bonnet: - brass for R120-01 to -04, - aluminum for R120-06 to -32 Inner parts: brass Membrane: PTFE on NBR carrier

Please Contact Us to Order to offer competitive prices and delivery time for Aircom - R120-04FK07_01 pressure regulator number, also you may ask some other model number is well. We can offer competitive price, and delivery time with wide products distribution network in United Kingdom Industrial products Market.

WE SELL ONLY NEW AND ORIGINAL PRODUCTS!

Our company is not an authorized distributor. All rights are reserved by the manufacturers and their official partners.
