RF1M80P00B0230S00  - Ascon United Kingdom  Sales

BRAND Ascon
Product RF1M80P00B0230S00
Description Low pressure sensors with connection head
Internal code 3311987
Weight 0.5
Technical specification Replaces type ZTR22M/1P Straight RTD, 5 to 8 mm sheath o.d., optional fixed attaching device RF1(A)(B)-(C)(D)(E)-(F)(G)-(H)(I) (A) Connection head C: Cylindical IP54 M: Miniature IP67 S: Standard IP67 T: Standard IP67, optional transmitter N: Nylon IP65 Y: Nylon IP65, optional transmitter X: EEx d IIB F: EEx d IIB, IP65, optional transmitter (B) Diameter 50: 5,0 mm 60: 6,0 mm 80: 8,0 mm (C) Value in [ohm] at 0°C P: Pt100 DIN - IEC X: Pt500 DIN - IEC Y: Pt1000 DIN - IEC Z: Ni100 DIN - IEC (D) N° elements / wiring / accuracy 0: 1xRTD, 3-wire, Class B 1: 1xRTD, 3-wire, Class A 2: 1xRTD, 3-wire, 1/3 Class B 3: 1xRTD, 4-wire, 1/3 Class B 4: 1xRTD, 4-wire, 1/3 Class B 5: 2xRTD, 2x2-wire, Class B 6: 2xRTD, 2x3-wire, Class B 7: 2xRTD, 2x3-wire, Class.A 8: 2xRTD, 2x3-wire, 1/3 Class B (E) Type of resistor 0: Ceramic, 750°C max. 1: Thin film, 250°C max. (F) Sheath material B: AISI 316 (1.4541) (G) Sheath length 0080: 80mm (min.) ... 0500: 500mm (max.) (H)Type of thread S: without D: M10 x 1,5 (only for diameter 5+6 mm) E: 1/8" Gas (only for diameter 5+6 mm) F: ¼" Gas H: 3/8" Gas I: 1/2 " Gas M: 1/8" NPT (only for diameter 5+6 mm) N: ¼" NPT P: 3/8" NPT Q: ½ NPT (I) cooling extension length 00: without 05: 50 mm 08: 80 mm 10: 100 mm

Please Contact Us to Order to offer competitive prices and delivery time for Ascon - RF1M80P00B0230S00 Low pressure sensors with connection head number, also you may ask some other model number is well. We can offer competitive price, and delivery time with wide products distribution network in United Kingdom Industrial products Market.

WE SELL ONLY NEW AND ORIGINAL PRODUCTS!

Our company is not an authorized distributor. All rights are reserved by the manufacturers and their official partners.
