BRAND | J+J Automation |
Product | S4C000309 |
Internal code | 4274834 |
Custom code | 85437090 |
Technical specification | J4C-S55 F05/ F07 17mm Standard with Dome IP67 quarter-turn actuator - All-voltage 24-240VAC + 24-135VDC - Brushless motor with long service life, 75% ED - Manual override, visual position indicator - 2 potential-free limit switches and 2 distance switch - Integrated shutter heater, electronic Torque Limitation and Protection Circuit - Drive according to DIN EN 15714-2. Plug connection supply: DIN EN175301-803 Shape A Plug connection end positions: Industrial Connectors Form C - Robust PA6 plastic housing - Valve interface according to ISO5211 - F05/F07, 17mm star recording (parallel and 45°). (The operating instructions must be strictly observed!) |
Please Contact Us to Order to offer competitive prices and delivery time for J+J Automation - S4C000309 number, also you may ask some other model number is well. We can offer competitive price, and delivery time with wide products distribution network in United Kingdom Industrial products Market.
WE SELL ONLY NEW AND ORIGINAL PRODUCTS!
Our company is not an authorized distributor. All rights are reserved by the manufacturers and their official partners.
