BRAND | Aviteq |
Product | SCE-EN60-2 |
Internal code | 4932448 |
Technical specification | 26775 SCE-EN60-2 440.. 480V 60HZ 15A IP20 CONTROL 200 x 62 x 200 mm (HxWxD) dimensions 2.2 kgNominal weight (pcs) 85365003Customs tariff HS code VIBTRONIC® -S controller for connecting AVITEQ vibrating conveyors. The swing width of the conveyor can be adjusted continuously on the connection device become. Delivery range of close to 0 to 100%. With a complete set of potentiometers for manual swing range adjustment. Electromagnetic compatibility (EMC) in accordance with the applicable EC Directive checked. To protect the thyristors in the controller, there is a install super-fast protection (Superflink or Ultrarapid). Vibration rate SC/E.. 60.. 3,600 min-1 Version For installation in on-site control cabinets Perforated steel housing RAL 5018 powder-coated power cable without Network fluctuation compensation ± 10%, the oscillation width remains constant Proportional change in the setpoint range Switch release (continuous contact, potential-free) or Voltage signal +24 V (DC) Inputs external control variables 0-10V (DC), 0-20mA (DC), 4-20mA (DC) Remote monitoring outputs, relay output Main dimensions approx. H200 x W62 x D200 mm Protection class IP20 according to DIN EN 60529 |
Please Contact Us to Order to offer competitive prices and delivery time for Aviteq - SCE-EN60-2 number, also you may ask some other model number is well. We can offer competitive price, and delivery time with wide products distribution network in United Kingdom Industrial products Market.
WE SELL ONLY NEW AND ORIGINAL PRODUCTS!
Our company is not an authorized distributor. All rights are reserved by the manufacturers and their official partners.
