BRAND | Steimel |
Product | ASF3-32RD-162586R |
Description | gear pump unit |
Internal code | 4583650 |
Custom code | 84136039 |
Technical specification | Gear pump unit: SF 3/32 RD - VLFM Item no.: ASF3-32RD-162586R Dimension sheet: DPA053D-100LFM-R31 Spare parts list: DET053032RD-165R Suction and pressure connection: SAE 1 1/2 Housing parts: EN-GJL-250 (GG-25) Pinion shafts, noise opti.: 16MnCrS5, egh., oblique galv. Shaft seal: radial shaft seal elastomers: FKM Speed: 950/1140 rpm. pressure relief valve Opening pressure: 8 bar Setting range: 2-18 bar Rotation direction: right Test run: yes, with HLPD 46 Bellhousing: BLF053250128LA21 Coupling: BKUA055-1928-301 three-phase motor: LDM100-06-032 (Birkenbeul) Engine data: Power 1/2:1.5 /1.7 kW Speed 1/2:1000/1200 rpm. Voltage/ frequency 1:230/400 volts at 50 Hz Voltage/ frequency 2:265/460 volts at 60 Hz Efficiency class: IE3 with additional plate without IE3 and CE marking for Installation height: 3500 m above sea level Voltage/frequency: 220-240/380-420 V at 50/60 Hz reduced power: 1.23 kW 250-280/440-480 V at 60 Hz reduced power: 1.4 kW Degree of protection: IP 55 Insulation class: F Design: B 5 Aggregate paint: without Type plate: ETY924-D-E—PE02 Storage: multi-layer MD Pumping medium: lubricating oil Viscosity: 50-5000 cSt Flow rate: approx. 32.7/39.3 l/min. pressure: 5 bar |
Please Contact Us to Order to offer competitive prices and delivery time for Steimel - ASF3-32RD-162586R gear pump unit number, also you may ask some other model number is well. We can offer competitive price, and delivery time with wide products distribution network in United Kingdom Industrial products Market.
WE SELL ONLY NEW AND ORIGINAL PRODUCTS!
Our company is not an authorized distributor. All rights are reserved by the manufacturers and their official partners.
