SK42-R150Z SHR-100LP/4 TF - Nord United Kingdom Sales

BRAND	Nord
Product	SK42-R150Z SHR-100LP/4 TF
Description	electric motor
Internal code	4796914
Technical specification	Product name Spannradgetr.Mot. m.Keilr.ver. PREM AL (B) asynchronous motor series Motor type 3-Ph AC Motor AxAB Motor speed 1.460 rpm Translation 85.10 Output speed 44,000 rpm Output speed 2 6.700 rpm Operating factor 1.80 Output torque M2 (Nm) 440.00 Output torque 2 M2 (Nm) 796.00 Power (kW) 2,200 Voltage (V) 230/400 Frequency (Hz) 50 Efficiency class IE3 S1 operating mode Motor protection class IP55 Insulation class F Current Rating 1 (AMP) 8.13 Current Rating 2 (AMP) 4.68 Cosine 1 0.76 M2 Z gearbox design Case type Foot housing WIV mounting cylinder selection WIV mounting cylinder Wave size 45X90 Open vent, with transport lock Thermal motor protection cold conductor, 3x155°C Star circuit type Terminal box layer/cable insert 2/I Type variable speed gearbox R150 Arrangement (U_Z) Z RV 6.50 translation Adjustable motor drive assembly Adjustment Angle adjustment Scale handwheel display Lubricant type mineral oil ISO VG 220 Lubricant quantity (l) 4,500 Oil grade CLP 220 Shade 5009 Azure Paint type solid color Basic painting instruction (2) CE logo Yes CCC logo No Mexico NOM certificate No UL No CSA No DoE CC No CSA ev No Alto Rendimento No Korea Energy Label No

Please Contact Us to Order to offer competitive prices and delivery time for Nord - SK42-R150Z SHR-100LP/4 TF electric motor number, also you may ask some other model number is well. We can offer competitive price, and delivery time with wide products distribution network in United Kingdom Industrial products Market.

WE SELL ONLY NEW AND ORIGINAL PRODUCTS!

Our company is not an authorized distributor. All rights are reserved by the manufacturers and their official partners.
