SLPP25-970 - Banner Engineering United Kingdom Sales

BRAND	Banner Engineering
Product	SLPP25-970
Description	Safety light curtain (emitt. + receiv. pair)
Internal code	761782
Weight	1
Technical specification	Defined Area Height Range (mm) >950 - <=1300 Max Operating Range (m) >4 - <=8 Low Profile Yes Primary Housing Material Aluminum Safety Level Type 4 Effective Aperture Angle Type 4 Per IEC 61496-2 Connector Type Removable Disconnect Defined Area Height (mm) 970 Dimensions WxD (mm) 28 x 26 Overall Length (mm) 970 External Monitoring Device 1 or 2 Channel Fixed Blanking Yes Housing Finish Yellow Polyester IP Rating IP65 Operating Distance (m) 0.1 - 7 Operating Voltage 24 V dc +/- 15% Operating Temperature 0 to +55 deg. C; RH 95% PL Rating Ple Recovery Time 33-220 / 109-800 Resolution (mm) 25 Reduced Resolution Yes Response Time 25.5 SIL Rating SIL3; CL3 Electrical Safety Class III Scan Code Selectable Shock 10g at 16ms (6000 cycles) Short Protection Yes System Type Emitter/Receiver Pair Vibration 10-55 Hz at 0.35 mm Auxiliary Output Yes Fault Output Yes Housing Material Aluminum; Zinc; Acrylic OSSD Rating 24 V dc at 0.5 A each Supply Current 210 mA max. Trip/Latch Output Selectable Test Input Yes Feature: End-to-End Sensing Yes

Please Contact Us to Order to offer competitive prices and delivery time for Banner Engineering - SLPP25-970 Safety light curtain (emitt. + receiv. pair) number, also you may ask some other model number is well. We can offer competitive price, and delivery time with wide products distribution network in United Kingdom Industrial products Market.
