S/N: 812.254.L1 - ARCA United Kingdom Sales

BRAND	ARCA
Product	S/N: 812.254.L1
Description	Oxygen Line Control Valve
Internal code	4840600
Technical specification	App-No:1016040 Series:812.254.L1 Valve type: Gas Control valve ARCA 08C with Actuator 812 and Positioner 827A.E2-A00M1 Medium: Oxygen Temperature [°C] : <100 Nominal value [m3/h] : P1=2 MPa, P2=0,06-0,22 MPa @Qmin, P2=1,08 MPa @Qnom, P2=1,23 MPa@Qmax; Qmin=45 Nm³/min, Qnom=760 Nm³/min, Qmax=850 Nm³/min Body Type: DS DN:200mm PN:40 bar , Kv:320 GL-L1 Seat Ø:130/127 mm Stroke:60mm Material:1.4581/1.457.1/1.4571 Function:O Servo Motor:MF3-60* Air Supply:max 4 bar Signal Range: 1.5-3.0 bar 812-34662-OB0 / F20.CG001-FCV09 Valve media failure to: Close PLC Analog Input (4-20 mA): 1 Input, PLC Active for valve position PLC Analog Output (4-20 mA):1 Output, PLC Active Remarks:Spindle sealing with bellows seal bonnet, position feedback module; Valve Body/Flange: Cast-steel, Seat and Plug: high-grade steel. Each part which comes into contact with Oxygen is to provided in Stainless Steel and must be oil and grease free

Please Contact Us to Order to offer competitive prices and delivery time for ARCA - S/N: 812.254.L1 Oxygen Line Control Valve number, also you may ask some other model number is well. We can offer competitive price, and delivery time with wide products distribution network in United Kingdom Industrial products Market.

WE SELL ONLY NEW AND ORIGINAL PRODUCTS!

Our company is not an authorized distributor. All rights are reserved by the manufacturers and their official partners.

More products of ARCA

F&R 961 1/4"NPT Mano 0-6 MS Poly, 2242329

type 961 Filter and pressure reducing station 1? 4 "NPT Enclosures in aluminum, external parts in Endstahl, Filter material: gesinteter plastic, 40 microseconds, Input: 1.4 to 17 bar g (250PSI) Output "Adjustable 0 to 6 bar g with manometer 0 to 6 bar / 0-86 psi / MS / plastic Air set type 961, 1/4 "NPT body in aluminum, outer parts in stainless steel, filter material: sintered plastic, Micron 40 input: 1.4 to 17 g bar (250PSI) with gauge 0 to 6 bar / 0-86 PSI / brass / poly

GASKET, ITEM NO: 143, FOR DN100 PN160 CONTROL VALVES

GASKET, ITEM NO: 144, FOR DN100 PN160 CONTROL VALVES

GASKET, ITEM NO: 168, FOR DN100 PN160 CONTROL VALVES

GASKET, ITEM NO: 58, FOR DN100 PN160 CONTROL VALVES

HEX. NUT, ITEM NO: 57, FOR DN100 PN160 CONTROL VALVES

NUT, ITEM NO: 81, FOR DN100 PN160 CONTROL VALVES

PACKING SET, ITEM NO: 156, FOR DN100 PN160 CONTROL VALVES

PISTON RING, ITEM NO: 177, FOR DN100 PN160 CONTROL VALVES

SCREW BOLT, ITEM NO: 80, FOR DN100 PN160 CONTROL VALVES

SEALING ELEMENT, ITEM NO: 180, FOR DN100 PN160 CONTROL VALVES

SEAT, ITEM NO: 20, FOR DN100 PN160 CONTROL VALVES

SLIDE BEARING, ITEM NO: 164, FOR DN100 PN160 CONTROL VALVES
