| BRAND | CD AUTOMATION |
| Product | Typ: RS1ABCDEFGHIKL |
| Description | Single-phase thyristor controllers REVO S series |
| Internal code | 4478527 |
| Technical specification | Item number RS1030-40SZ0000X1 REVOS-A-B-C-D-E-F-G-H-I-J-K J= X: user manual, German=standard (A) Load current (widthexexdepth) (with option) 030:30A (36 x 121 x 125 mm/36 x 121 x 185) 0.44 kg/0.61 kg 035:35A (36 x 121 x 125 mm/36 x 121 x 185) 0.44 kg/0.61 kg 040:40 A (36 x 121 x 125 mm/36 x 121 x 185) 0.44 kg/0.61 kg 060:60 A (93 x 269 x 185 mm) 3.40 kg 90:90 A (93 x 269 x 185 mm) 3.60 kg 120 120 A (93 x 273 x 185 mm) 3.60 kg 150 A (93 x 273 x 185 mm) 3.60 kg 180:180 A (93 x 273 x 185 mm) 3.60 kg 210:210 A (93 x 273 x 185 mm) 3.60 kg 300:300 A (137 x 520 x 270 mm) 15.00 kg 400:400 A (137 x 520 x 270 mm) 15.00 kg 500:500A (137 x 520 x 270 mm) 15.00 kg 600:600 A (137 x 520 x 270 mm) 15.00 kg 700:700 A (137 x 520 x 270 mm) 15.00 kg 800:800 A (137 x 560 x 270 mm) 17.20 kg (B) load voltage max 4:480 V 6:600 V 7:690 V (C) Mains voltage - devices =< 210A - without HB, without analog input 0: without - devices =< 210A - with HB and/or analog input 4:12-24 V ac/dc - Only for devices > 210A - The load voltage must are in the range of mains voltage 1:90-135 V 2:180 - 265 V 3:238 - 330 V. 5:342 - 528 V 6:540-759 V 7:540-759 V (D) input S: SSR V: 0-10Vdc A: 4-20 mA. (E) Operating mode - for all devices Z: ZC Zero Crossing - only in conjunction with analog input 4:BF4 8:BF8 6:BF16 (F) Repatriation 0: without (G) option - only for load currents =< 40A 0: no backup F: with fuse+holder Y: fuse + CT (current transformer) H: fuse + CT (current transformer) +HB (partial load error) X: fuse+CT (current transformer) +HB+ “flat wiring system”. - for load currents > 40A F: integrated fuse H: fuse + CT (current transformer) +HB (partial load error) (H) fan 0: without 1: with 110V fan (optionally from 120A) 2: with 220V fan (standard from 120A) 3: with 24VDC fan (from 120A) (I) UL 0: without UL L: with cUL (when available) (J) User manual 0: without 1: Italian 2: English 3: German (where available) 4: French (K) version 1: default |
Please Contact Us to Order to offer competitive prices and delivery time for CD AUTOMATION - Typ: RS1ABCDEFGHIKL Single-phase thyristor controllers REVO S series number, also you may ask some other model number is well. We can offer competitive price, and delivery time with wide products distribution network in United Kingdom Industrial products Market.
