Buy BNA-EN20/40/B1-MG-M400-V60x2-MRF-3/M-ZVSS 250 from Ksr Kuebler in United Kingdom

BRAND	Ksr Kuebler
Product	BNA-EN20/40/B1-MG-M400-V60x2-MRF-3/M-ZVSS 250
Description	Bypass level gauges
Internal code	4455445
Weight	10.2
Custom code	90261089
Technical specification	BNA-CMB02000215-0100400D0880DZZS BNA-BMDGAECEARZZZZZZZHZZZGAZZ12KVB25031ZZZZ BLR-CMZZ4WZA210400Z# BGU-C5ZZS2ZZZZZZ pressure: 20 bar temp.: -10°C... 215 °Cdensity, medium: 880 kg/m³ Design: PED 2014/68/EU (AD2000) Classification according to PED 2014/68/EU: category I, module A, fluid group 1 Test pressure: 36 bar Chamber dimensions: 60.3 x 2 mm stainless steel 1.4571 (316Ti) Process connection: flange DIN EN 1092-1 DN 20 PN 40 form B1 Centre distance: 400 mm Measuring range: 400 mm Chamber termination top: tube base Bottom chamber end: flange D130 Drain: plug screw G 1/2" Floats: ZVSS250 Display: BMD-FA, aluminum profile with stainless steel flaps Damping element: damping spring at the bottom with cover Seal (s): Sigraflex Universal Pro Screws: stainless steel A4-70 (M) overhang top (T): 100 mm projection bottom (U): 225 mm Side spacing (X): 100 mm (max) BGU-VHT Magnetic switch for bypass BGU-VHT Basic type: BGU-VHT, reed, high temperature, stainless steel housing, cable gland Max. AC 230 V, 40 VA, 1 A/DC 230 V, 20 W, 0.5 A Number of switches: 3 Electrical connection: cable gland M20x1.5 mm Process temperature -60°C to 380°C Add Microtherm pad to switch Protection class: IP66/68 Magnetic switch on the right of the roller display MG-AVK15/MT-L550/M400/14 Transmitter bypass mounting Reed type BLR-SA Pad: 3 mm microtherm Material: stainless steel 1.4571 (316Ti) Housing: aluminium IP66/68 cable gland M20 x 1.5 mm LCD display: None Output signal: 3-wire potentiometer Housing arrangement: angled at the top 100% brand (L1): 0 mm 0% mark: 0 mm Measuring range: 400 mm Tube length: 550 mm Contact grid: 15 mm *** Additional order information: - Total resistance approx. 3-10kOhm The BLR must not be insulated when using Microtherm

Discover the superior quality and performance of the Ksr Kuebler BNA-EN20/40/B1-MG-M400-V60x2-MRF-3/M-ZVSS 250 with RADWARD LTD in United Kingdom . Whether you are looking for reliability or efficiency, this product meets all your industrial needs.

The BNA-EN20/40/B1-MG-M400-V60x2-MRF-3/M-ZVSS 250 is designed to provide optimal performance and durability in various applications. Known for its high-quality construction and innovative features, it is a preferred choice for professionals.

Key Features of BNA-EN20/40/B1-MG-M400-V60x2-MRF-3/M-ZVSS 250 :

High Performance: Engineered to deliver exceptional results.
Durable Construction: Built with high-quality materials for long-lasting use.
Innovative Design: Incorporates the latest technology for enhanced efficiency.
Cost-Effective: Offers great value for money with competitive pricing.

At RADWARD LTD , we offer the BNA-EN20/40/B1-MG-M400-V60x2-MRF-3/M-ZVSS 250 at competitive prices and with the fastest delivery times across United Kingdom . Our expert team is ready to assist you with all your inquiries and provide tailored solutions to meet your specific needs.

Why Choose RADWARD LTD ?

Expert Assistance: Get help from our knowledgeable team for all your product-related questions.
Competitive Prices: We offer some of the best prices in the market.
Fast Delivery: Benefit from our efficient delivery network for quick turnaround times.
Customer Satisfaction: Our commitment to customer service ensures a great buying experience.

Get Your Quote Today! Ready to enhance your operations with the BNA-EN20/40/B1-MG-M400-V60x2-MRF-3/M-ZVSS 250 ? Contact us now for a personalized quote. Fill out the form below or send us an email with your inquiry. Let us help you make a cost-effective, quality-driven choice for your business.

Important Notice: While we supply Ksr Kuebler products, RADWARD LTD is not an authorized distributor. All rights are reserved by the manufacturers and their official partners.

Where can I buy BNA-EN20/40/B1-MG-M400-V60x2-MRF-3/M-ZVSS 250 by Ksr Kuebler in United Kingdom?

You can purchase BNA-EN20/40/B1-MG-M400-V60x2-MRF-3/M-ZVSS 250 by Ksr Kuebler from RADWARD LTD. We serve customers across United Kingdom, offering competitive prices and reliable service.

What is the price of the BNA-EN20/40/B1-MG-M400-V60x2-MRF-3/M-ZVSS 250?

For customized pricing and availability, please fill out our contact form or give us a call. We are dedicated to providing solutions that align with your specific requirements.

Who is the official distributor or seller of Ksr Kuebler in United Kingdom?

While we are not the official distributor or seller of Ksr Kuebler in United Kingdom, we source our products from reliable channels and offer you original Ksr Kuebler equipment at competitive prices.

How can I access BNA-EN20/40/B1-MG-M400-V60x2-MRF-3/M-ZVSS 250 catalogs, user manuals, technical documents, and PDFs?

You can access catalogs, user manuals, and technical documents for BNA-EN20/40/B1-MG-M400-V60x2-MRF-3/M-ZVSS 250 on our website. Visit our resources section or contact us directly for specific documents.

Do you provide technical support for BNA-EN20/40/B1-MG-M400-V60x2-MRF-3/M-ZVSS 250?

While we do not offer direct technical support, we can assist you in contacting the manufacturer to ensure you receive the support you need.
