BRAND | Kobold |
Product | UMC4-B11A00H |
Description | FLOWMETER |
Internal code | 4737363 |
Technical specification | TMU-S025-317B-A00-A0-10/UMC4-B11A00H 50000001 Coriolis mass flowmeter Model code sensor: TMU-S025-317B-A00-A0-10-0-H Model code measurement converter: UMC4-B11A00H Process data: Display range [kg/h]: 3000 Medium name: Molasses Density [kg/m3]: 1350 Viscosity [mPas]: 1 Process temperature [°C]: 60 (max 150) Process pressure [pe bar]: 4 Flow direction: left-right Sensor data: Parts in contact with the medium: 1.4571 (316Ti) /1.4404 (316L) Standard measurement range: min. 0 - 3,000 kg/h max. 0-30,000 kg/h Process connection: DN40 PN40 Form B1 DIN/EN1092 Pressure resistance: 40 bar Sensor housing: stainless steel housing 1.4301 (304) Housing pressure resistance: 0 bar Sensor protection class: IP66 (EN60529) Heating/cooling: none Heating/cooling connection: without Measurement converter arrangement: built-in measurement converter Temperature range: -20 to 100°C Sensor connection: - Approval: none Mass flow calibration: standard, 3-point Calibration density: none Overall length: 600 mm PED: CAT II Type: UMC4 Mounting type: built-in measurement converter Sensor connection: - Cable screw thread: M20x1.5 Display and control unit: built-in control unit Display language: English Supply voltage: 90-265V AC; 50/60 Hz Current output 1 (passive): 0/4-20 mA with HART® protocol mass flow rate, temperature volume flow rate, density Current output 2 (passive): 0/4-20 mA mass flow rate, temperature volume flow rate, density Pulse output 1:.. Imp/kg passive Status output 2: passive Forward/backward measurement alarm MIN/MAX flow MIN/MAX density MIN/MAX temperature Approval: none Ignition protection type signal outputs: without Ambient temperature: -20 to +60°C Protection class measurement converter: IP66 (EN60529) Characteristics: Measurement uncertainty (measurement range): ± 0.1% of the measured value plus zero point stability Repeatability: ± 0.05% of measured value ± 1/2 zero point stability Pressure loss: ~ 0.02 bar at 3000 kg/h |
Please Contact Us to Order to offer competitive prices and delivery time for Kobold - UMC4-B11A00H FLOWMETER number, also you may ask some other model number is well. We can offer competitive price, and delivery time with wide products distribution network in United Kingdom Industrial products Market.
WE SELL ONLY NEW AND ORIGINAL PRODUCTS!
Our company is not an authorized distributor. All rights are reserved by the manufacturers and their official partners.
