BRAND | Elettrotec |
Product | VCM1ABN18KT450 |
Description | vacuum switch |
Internal code | 4828147 |
Custom code | 90268020 |
Technical specification | Z710-00683-99999 Vacuum switch -0.2 - -0.9mmbar - closer VCM1ABN18KT450 Pressure switch (membrane) - closer Adjustment: screw between contacts Setting range: -0.2 to -0.9 bar Connection thread: 1/8" tapered Material: brass Seal: NBR max. static pressure: 20bar max. ohmic load: 0.5A at 48VDC Temperature range: -5°C - 60°C Switching cycles: 200/min Hysteresis at 25°C: 0.1 bar Tolerance at 25°C: ± 0.1 bar Lifespan: 1,000,000 cycles Set to -0.45mmbar increasing |
Please Contact Us to Order to offer competitive prices and delivery time for Elettrotec - VCM1ABN18KT450 vacuum switch number, also you may ask some other model number is well. We can offer competitive price, and delivery time with wide products distribution network in United Kingdom Industrial products Market.
WE SELL ONLY NEW AND ORIGINAL PRODUCTS!
Our company is not an authorized distributor. All rights are reserved by the manufacturers and their official partners.
