| BRAND | IEI |
| Product | WSB-H610-R10 |
| Description | WSB-H610-R10 |
| Internal code | 648301 |
| Technical specification | CPU LGA1155 socket supports Intel® Core™ i7/i5/i3/Pentium®/Celeron® processor PCH Intel® H61 BIOS UEFI System Memory Two 240-pin 1333/1066MHz dual-channel DDR3 & DDR3L (1.35V) DIMMs supported (system max. 16GB) Ethernet LAN1: Realtek RTL8111E PCIe GbE controller with ASF 2.0 support LAN2: Realtek RTL8111E PCIe GbE controller I/O Interface 2 x RS-232 1 x RS-422/485 1 x LPT 1 x FDD 1 x PS/2 KB/MS 1 x 6-pin wafer for KB & MS 7 x USB 2.0 (1 on rear, 6 by pin header) 4 x SATA 3Gb/s (H61 doesn't support AHCI & RAID) Digital I/O 8-bit digital I/O (4-bit input, 4-bit output) Super I/O Fintek F81866 TPM 1 x TPM connector (2x10 pin) SMBus 1 x 4-pin wafer Audio Supports 7.1 channel HD audio by IEI AC-KIT-892HD-R10 kit Display Interfaces 1 x VGA (up to 2048 x 1536 @75Hz) 1 x DVI-D (up to 1920 x 1200 @60Hz) (via header to IO-KIT-001-R20 DVI-D/USB module) (optional) Expansion PCI signal and ISA signal via golden finger Watchdog Timer Software programmable supports 1~255 sec. system reset Power Supply 5V/12V, AT/ATX support Power Consumption 5V@4.53A, 12V@0.19A, Vcore_12V@7.81A, 5VSB@0.18A (3.4GHz Intel® Core™ i7-2600K with two 2GB 1333MHz DDR3 memory) Graphic Intel® HD Graphics Gen 6 supports DX10.1 and OpenGL 3.0 Full MPEG2, VC1, AVC Decode Operating Temperature -10°C ~ 60°C Storage Temperature -20°C ~ 70°C Humidity 5% ~ 95%, non-condensing Dimensions 338 mm x 122 mm Weight GW: 1000g/NW: 260g Embedded Controller ITE IT8519E Front Panel 1 x Front panel (power LED, HDD LED, speaker, power button, reset button) I2C 1 x 4-pin wafer PCIe-PCI Bridge ITE IT8892E PCI-ISA Bridge ITE IT8888G Fan Connector 1 x 4-pin smart fan connector 1 x 4-pin system fan connector |
Please Contact Us to Order to offer competitive prices and delivery time for IEI - WSB-H610-R10 WSB-H610-R10 number, also you may ask some other model number is well. We can offer competitive price, and delivery time with wide products distribution network in United Kingdom Industrial products Market.
WE SELL ONLY NEW AND ORIGINAL PRODUCTS!
Our company is not an authorized distributor. All rights are reserved by the manufacturers and their official partners.
