| BRAND | Demag |
| Product | ZBA 90 A 8 B007 H 3 |
| Description | cylinder rotor engine |
| Internal code | 4605673 |
| Technical specification | Technical specifications: Engine speed 820 rpm Power 0.44 KW Duty cycle 60% Motor protection class IP 55 Ambient temperature -20...+60 °C Altitude <= 1000 m Type code ZBA 90 A 8 B007-H-3 Type H Terminal box position on the left, 3rd Motor installation position horizontal Total weight, net approx. 18 kg Electrical data: Mains voltage D/Y 265/460 V Mains frequency 60 Hz Current D/Y 3.20/1.80 A Technical data brake: Braking torque 3.8 Nm Voltage 207VDC current 0.09A with brake rectifier GE 460 V AC Furnishing: 3 PTC thermistors for shutdown at 160 °C with varistor protection with phase isolation for converter operation Motor circuit D/Y with sprocket for direct attachment to A60T i=177.00 fan disc heavy increased degree of protection selected ambient temperature: 50 ° C Heat class F Cover strip brake for increased protection class IP55/IP65 Degree of protection of the brake IP55/IP65 coloring: RAL 5009, azure blue with special insulation for use in a humid and hot atmosphere Documentation: assembly Instructions EU documents according to the Machinery Directive |
Please Contact Us to Order to offer competitive prices and delivery time for Demag - ZBA 90 A 8 B007 H 3 cylinder rotor engine number, also you may ask some other model number is well. We can offer competitive price, and delivery time with wide products distribution network in United Kingdom Industrial products Market.
WE SELL ONLY NEW AND ORIGINAL PRODUCTS!
Our company is not an authorized distributor. All rights are reserved by the manufacturers and their official partners.
Control switch DST9SP222
Control switch (without cable)
Controller
Control button
(Contactor 230 / 220V50HZ)
(Contactor 230 / 220V50HZ)
Contactor double Coil
contactor
Contactor
DSW 3TF8633 230/220V50HZ 87559033
Contactor (replacement for 87,559,044 new Ident no. 87559033 = same product)
Contactor 230 / 220V50HZ
EKDH 210 H16 K V2 F4 -Demag Fahrwerksantrieb für Einschinenkatze KMF 80 A 8/2
(Spare part for DEMAG hoist EKDH210 H16 F4 K V2 with serial number 317,271 as supplied just below DEMAG order number 57387200 in 1993)
EKDH 210 H16 KV2-2/1 P/N:KMF 80 A8/2
Motor Installing Situation: Movement Type:Cross Travel Crane Type: EKDH 210 H16 KV2 - 2 /1 Capacity: 2 Ton
EKDH 310 H20 KV1-2 /1 F6 ,obsolete, replaced by AFL04 KBV71 A 8/2 / 57387000
(Spare part for DEMAG hoist EKDH310 H20 F6 K V2 with serial number 317247 as supplied just below DEMAG order number 573870000 in 1993)
EKDH 310 H20 KV1-2/1 F6 P/N:KBH 140 82/12
Motor Installing Situation: Movement Type:Long Travel Crane Type: EKDH 310 H20 KV1 - 2 /1 F6 Capacity: 2 Ton
EKDH 525 H12 KV2 F6 / Motorset KBH140B2/12 DH 500 / 52728700
(Spare part for DEMAG hoist EKDH 525 KV2 H12 F6 with serial number 316,283 as supplied just below DEMAG order number 52728700 in 1993)
EKDH 525 H40 K V2 1 F6 / Motorset KBH140B2/12DH 500 / 52729100
(Spare part for DEMAG hoist EKDH 525 K V2 H40 F6 1 as supplied exactly with serial number 316,283 under DEMAG order number 52729100)
EUDH 320 H20 KV2-1/1 F6- obsolete, replaced by AFL04 KBV71 A 8/2 / 57387100
(Spare part for DEMAG EKDH320 H20 F6 K V2 with serial number 317254 as supplied just below DEMAG order number 57387100 in 1993)
