BRAND | Demag |
Product | ZBA 225 AL 4 B680 B5 1 |
Description | motor |
Internal code | 4943358 |
Technical specification | Technical data: Engine speed 1770 rpm Output 44.40 kW Operating time 60% Motor protection class IP 54 Ambient temperature -20... +60 °C Installation height ≤ 1000 m ZBA 225 AL 4 B680-B5-1 design wrench B5 design Terminal box position on the right, 1 Horizontal motor installation position Electrical data: Line voltage D/Y 280/480 V Line frequency 60 Hz Current D/Y 112.00/66.00 A Brake technical data: Braking torque 450.0 Nm Voltage 216 V DC Current 0.68 A with GS 480 V AC brake rectifier equipment: 3 cold conductors for shutdown at 160 °C with phase insulation for inverter operation D/Y motor circuit Light fan disc Built-in exhaust fan 230400 V 50/60 Hz (IP54) A 450 flange selected ambient temperature: 60° C Warmth class F Warmth class F Noise-reduced design color scheme: RAL 5009, azure blue documentation: Assembly instructions |
Please Contact Us to Order to offer competitive prices and delivery time for Demag - ZBA 225 AL 4 B680 B5 1 motor number, also you may ask some other model number is well. We can offer competitive price, and delivery time with wide products distribution network in United Kingdom Industrial products Market.
WE SELL ONLY NEW AND ORIGINAL PRODUCTS!
Our company is not an authorized distributor. All rights are reserved by the manufacturers and their official partners.
