RVS_16/SG-09 - Robuschi United Kingdom Sales

BRAND	Robuschi
Product	RVS_16/SG-09
Description	Pump with motor
Internal code	4007452
Technical specification	With the following configuration: Motor power (kW) 5.50 Motor poles 4 IEC shape motor B5 Water-soluble alkyd painting cycle Total painting thickness (um) 50 Final paint thickness (um) 50 Machine RAL code 5009 CE CE certificate EC declaration type II A Motor type Standard 50hz motor Motor brand ABB M3AA IE3 CE Category ATEX NOT Atex RVS vacuum pump series Service type Vacuum pump Vacuum pump size 16 UNI flange execution Choice of hydraulic seal Standard mechanical seal Bare axis mouth (DN) 65 Machine packaging type Mouth protection only Power frequency (Hz) 50 Description Modifiable RVS_16 / SG-09 Cast iron body G250. GS400-15 cast iron impeller. C40 BONIF steel shaft. Cast iron element G250. X5CrNiMo1712 stainless steel plate. Mechanical seal Burgmann MG12G60 BQ1VGG DIN 24960. Grease lubrication. Performance tolerance according to Robuschi specification TE3.S.0015 Estimated sound pressure level in free field at 1 m distance with the acoustically insulated pipes

Please Contact Us to Order to offer competitive prices and delivery time for Robuschi - RVS_16/SG-09 Pump with motor number, also you may ask some other model number is well. We can offer competitive price, and delivery time with wide products distribution network in United Kingdom Industrial products Market.
