BRAND | Faggiolati |
Product | G271T3V4-K50AA6 |
Description | Submersible Pump |
Internal code | 4230246 |
Technical specification | code 7220 Vortex impeller Free passage (mm) 50 Delivery spout (mm) 50 Cooling By surrounding liquid Electric motor M271T-1,6-400/50NY-IE3EX - (Watertight II 2G Ex c k db IIB T4 Gb) IP 68 protection Rated motor power (kW) 1,6 Direct Starter Type Power supply 3ph 400V-50Hz Rotational speed (rev/min) 2783 Insulation Class H Continuous Service S1 Submersible N-Neoprene electrical cable length. 10m Double Shaft Seal Operating temperature (°C) < 45 Pump protections Stator thermal protection Surface treatment Two-component epoxy painting Pump body CAST IRON EN-GJL-250 SHAFT DUPLEX ASTM A 890 gr. 4A UNS 31803 SAF 2205 Impeller EN-GJL-250+Ni Motor Seal Nitrile Sealing Rings Impeller Seal Silicon Carbide/Silicon Carbide Screws Class A4 AISI 316 Nitrile O-Rings Lifetime Lubricated Ball Bearings |
Please Contact Us to Order to offer competitive prices and delivery time for Faggiolati - G271T3V4-K50AA6 Submersible Pump number, also you may ask some other model number is well. We can offer competitive price, and delivery time with wide products distribution network in United Kingdom Industrial products Market.
WE SELL ONLY NEW AND ORIGINAL PRODUCTS!
Our company is not an authorized distributor. All rights are reserved by the manufacturers and their official partners.
