BRAND | Faggiolati |
Product | G271T1M4-L40AA0 |
Description | Submersible electric pump |
Internal code | 4807227 |
Technical specification | G271T1M4-L40AA0 Impeller type Single channel Free passage (mm) 40 Discharge diameter (mm) 65 Cooling By surrounding fluid Motor type M271T-2,8-400/50NN-IE3 - (Watertight, suitable for VFD) Mechanical prot. Degree IP 68 Rated motor power (kW) 2.8 Starting type Direct Supply 3ph 400V-50Hz Nominal speed (rpm) 2803 Winding insulation Class H S1 Continuous Duty Service Submersible N-Neoprene electric cable, length 10 m Double shaft seal Liquid max. temperature (°C) < 40 Surface painting Epoxy painting Cast Iron Diffuser EN-GJL-250 Duplex shaft ASTM A890 Gr.4A UNS 31803 SAF 2205 Cast Iron Impeller EN-GJL-250+Ni Upper seal Nitrile Lip Seal Lower seal Silicon Carbide/Silicon Carbide Screws A4 Class AISI 316 Nitrile O-Rings MATERIALS Ball bearings Ball Bearings, life lubricated |
Please Contact Us to Order to offer competitive prices and delivery time for Faggiolati - G271T1M4-L40AA0 Submersible electric pump number, also you may ask some other model number is well. We can offer competitive price, and delivery time with wide products distribution network in United Kingdom Industrial products Market.
WE SELL ONLY NEW AND ORIGINAL PRODUCTS!
Our company is not an authorized distributor. All rights are reserved by the manufacturers and their official partners.
