BRAND | Faggiolati |
Product | GM40B813R3-4T6SA2 |
Internal code | 4521518 |
Technical specification | Submersible Mixer, with multipolar electric motor and self-cleaning threeblades propeller, completely casted in stainless steel AISI 316L, hydraulic shape designed for high efficiency. Impeller type Propeller three blades Cooling By surrounding fluid Motor type M813T-5,2-400/50YY-IE - (Watertight, suitable for VFD) Mechanical prot. Degree IP 68 Rated motor power (kW) 5,2 Rated current (A) 12,1 Starting type Direct - Star/Delta Starting Supply 3ph 400/690V-50Hz Nominal speed (rpm) 706 Winding insulation Class H Duty service S1 Continuous Electric cable N-Neoprene submersible, length 10 m Shaft seal Double Mechanical Liquid max. temperature (°C) < 40 Pump protection Thermal Protection and Leakage Sensor in oil chamber. Surface painting Epoxy painting Thrust (N) 780 Propeller diameter (mm) 400 MATERIALS Shaft DUPLEX ASTM A890 gr. 4A UNS 31803 SAF 2205 Impeller Stainless Steel AISI 316 Upper seal Ceramic/Graphite Lower seal Silicon Carbide/Silicon Carbide Screws A4 Class AISI 316 O-Rings Nitrile Ball bearings Ball Bearings, life lubricated Guide Bar bracket Stainless steel AISI 304 Motor Casing Cast Iron EN-GJL-250 |
Please Contact Us to Order to offer competitive prices and delivery time for Faggiolati - GM40B813R3-4T6SA2 number, also you may ask some other model number is well. We can offer competitive price, and delivery time with wide products distribution network in United Kingdom Industrial products Market.
WE SELL ONLY NEW AND ORIGINAL PRODUCTS!
Our company is not an authorized distributor. All rights are reserved by the manufacturers and their official partners.
Pump
Pump
Submersible Pump
Shaft bushing
Shaft bushing protection
Electric pump
WASHER 6X10X1.5 RAME
WASHER 8X24 A2
WASHER 8X12X1,5 RAME
TENUTA MECCANICA / MECHANICAL SEAL FG1 2
O-RING 2-125 32.99X2.62 NITRILE
O-RING 4600 NITRILE
O-RING 2-150 72,69X2,62 NBR
WASHER 19X30X3 A2 AISI 304
PRESSCABLE GLAND 30X17H15 NEOP
PRELOADING SPRING LMKAS 62
MECHANICAL SEAL FA 30-2-B-X
CIRCLIP E 30 UNI 7435
WASHER 31X38X0.6 BU-57/F1 ACC.98762.
WASHER 10X16X1.5 RAME
O-RING 2-266 4800 202,79X3,53 NBR
PRESSCABLE SUPPORT 08319 G250
LOWER BEARING COVER G250 1 COR G210
IMPELLER
