G410R6V2-M64AA2 - Faggiolati United Kingdom Sales

BRAND	Faggiolati
Product	G410R6V2-M64AA2
Description	Electric pump
Internal code	4268357
Technical specification	7908 Vortex impeller Free passage (mm) 64 Delivery spout (mm) DN 80 Cooling to the surrounding liquid medium M410T-3.5-400/50YY-IE3 electric motor - (Watertight suitable for VFD) IP 68 protection Nominal motor power (kW) 3.5 Direct start type - Star/Triangle 3ph 400/690V-50Hz power supply Rotation speed (rev/min) 1392 Class H insulation S1 Continuous Service 10m long submersible N-Neoprene electric cable Double Mechanical Shaft Seal Operating temperature (°C) < 40 Pump protections Stator thermal protection - Water detection probe in oil chamber Surface treatment Two-component epoxy coating EN-GJL-250 CAST IRON pump body AISI 431 stainless steel shaft EN-GJL-250+Ni impeller Graphite/Ceramic motor seal Silicon Carbide/Silicon Carbide impeller Seal Class A4 AISI 316 fasteners Nitrile O-Rings MATERIALS Lifetime Lubricated Bearings Weight (Kg) 79 Suction port (m)

Please Contact Us to Order to offer competitive prices and delivery time for Faggiolati - G410R6V2-M64AA2 Electric pump number, also you may ask some other model number is well. We can offer competitive price, and delivery time with wide products distribution network in United Kingdom Industrial products Market.

WE SELL ONLY NEW AND ORIGINAL PRODUCTS!

Our company is not an authorized distributor. All rights are reserved by the manufacturers and their official partners.
