SCE-DN60-2 - Aviteq United Kingdom Sales

BRAND	Aviteq
Product	SCE-DN60-2
Description	CONTROLLER
Internal code	2026137
Weight	0.45
Custom code	85365003
Technical specification	SCE-DN60-2 440.. 480V 60HZ 15A IP20 CONTROL 200 x 62 x 200 mm (HxWxD) dimensions 85365003Customs tariff HS code VIBTRONIC® -S controller for connecting AviTEQ vibrating conveyors. The swing width of the conveyor can be continuously adjusted on the connecting device become. Delivery rate adjustment range of close to 0 to 100%. With a complete set of potentiometers for manual adjustment of the swing range. Electromagnetic compatibility (EMC) in accordance with the applicable EC Directive checked. To protect the thyristors in the controller, a super-fast protection (superflink or ultrarapid) to install. Oscillation rate SC/E.. 25... 1,500 min-1 SC/E.. 30.. 1,800 min-1 SC/E.. 50... 3,000 min-1 SC/E.. 60.. 3,600 min-1 Version For installation in an on-site control cabinet Perforated steel housing RAL5018 powder coated Power cable without Network fluctuation compensation ± 10%, the swing width remains constant Swinging range change in setpoint proportion Switch release (continuous contact, potential-free) or +24 V (DC) voltage signal Inputs external control variables 0-10V (DC), 0-20mA (DC), 4-20mA (DC) Outputs remote monitoring, relay output Main dimensions approx. H200 x W62 x D200 mm Protection class IP20 in accordance with DIN EN 60529

Please Contact Us to Order to offer competitive prices and delivery time for Aviteq - SCE-DN60-2 CONTROLLER number, also you may ask some other model number is well. We can offer competitive price, and delivery time with wide products distribution network in United Kingdom Industrial products Market.
