906210617000001 - Ephy Mess United Kingdom Sales

BRAND	Ephy Mess
Product	906210617000001
Internal code	4749826
Technical specification	PR-SPA-EX-WKF IBExU 14 ATEX 1281 U, II 2G Exia IIC Gb IECEx IBE 14.0058U, Exia IIC Gb EAC RU C-DE.BH02.в.00338/20, Exia IIC Gb U № 81831-21 Cable resistance thermometer, M-OK/MH 1Pt100, 3-wire circuit Class A ±0.15°C at 0°C in accordance with DIN EN 60751 stainless steel, encapsulation, ø3x20mm meet your structural requirements if the articles only have an ATEX partial certificate (U) and not an ATEX full certificate (X). EPHYMESS is unable to perform this check. Supply line: shielded hose cable 1x [4xAWG 26/7-copper silver/PTFE/polyimide foil/copper silver/PTFE, KL=15000mm, diameter: 3.2 mm] WH (RD/RD/WH), Measuring range: -60°C... +180°C Ambient temperature: -60°C... +180°C Dielectric strength: 0.5 kV AC. 50 Hz/1min. Shield not placed on sensor housing Umbrella folded down on the connection side incl. meter Certificate and passport Country of origin: Germany AL: N/ ECCN: N/ HS/Custom Tariff: 90259000 Net weight: 338.2 g/piece The user manual is delivered in German or English. ATTENTION: Please check with your ATEX representative that the above articles * 998100220000001 TR-Ex, EAEC RU C-EN.BH02.в.00338/20 (for LTH, NWT, WKF) Ignition protection type for LTH: 1Ex and IIC T6... T3 Gb Ex tb IIIC T80°C/T95°C/T130°C/ T180°C Db 1Ex ia IIC T6... T3 Gb Ex ia IIIC T80°C/T95°C/T130°C/T180°C Db Ignition protection type for NWT and WKF: Ex e II Gb U, Ex tb IIIC Db U Ex ia IIC Gb U, Ex ia IIIC Db U AL: N/ECCN: N The user manual is delivered in German or English. ATTENTION: Please check with your ATEX representative that the above articles meet your structural requirements if the articles only have an ATEX partial certificate (U) and not an ATEX full certificate (X). EPHYMESS is unable to perform this check. * 998140621000001 Metrological_certificate_ PR-Spa-ex/na-lth, PR-Spa-ex/na-WKF, PR-Spa-ex/na-nwt, No.: 81831-21, valid for Russia The official validity is determined by Database entry displayed

Please Contact Us to Order to offer competitive prices and delivery time for Ephy Mess - 906210617000001 number, also you may ask some other model number is well. We can offer competitive price, and delivery time with wide products distribution network in United Kingdom Industrial products Market.

WE SELL ONLY NEW AND ORIGINAL PRODUCTS!

Our company is not an authorized distributor. All rights are reserved by the manufacturers and their official partners.
