G210R3C1-M30AA2 - Faggiolati United Kingdom Sales

BRAND	Faggiolati
Product	G210R3C1-M30AA2
Description	Submersible pump
Internal code	4814859
Technical specification	879 Submersible pump, equipped watertight motor separated from the hydraulic part by an oil chamber, for sewage water Impeller type Three Channel Free passage (mm) 30 Discharge diameter (mm) DN 80 Cooling By surrounding fluid Motor type M210T-6-400/50YY-IE3 - (Watertight, suitable for VFD) Mechanical prot. Degree IP 68 Rated motor power (kW) 6,0 Starting type Direct - Star/Delta Starting Supply 3ph 400/690V-50Hz Nominal speed (rpm) 2842 Winding insulation Class H Duty service S1 Continuous Electric cable N-Neoprene submersible, length 10 m Shaft seal Double Mechanical Liquid max. temperature (°C) < 40 Pump protection Motor Thermal Protections - Leakage Sensor in oil chamber Surface painting Epoxy painting Suction (mm) DN 80 Rated current (A) 10,9 Diffuser Cast Iron EN-GJL-250 Shaft Stainless Steel AISI 431 Impeller Cast Iron EN-GJL-250+Ni Upper seal Ceramic/Graphite Lower seal Silicon Carbide/Silicon Carbide Screws A4 Class AISI 316 O-Rings Nitrile Ball bearings Ball Bearings, life lubricated

Please Contact Us to Order to offer competitive prices and delivery time for Faggiolati - G210R3C1-M30AA2 Submersible pump number, also you may ask some other model number is well. We can offer competitive price, and delivery time with wide products distribution network in United Kingdom Industrial products Market.
