G410R2C2-P80AA2 - Faggiolati United Kingdom Sales

BRAND	Faggiolati
Product	G410R2C2-P80AA2
Description	pump
Internal code	2044233
Weight	115
Technical specification	Submersible pump of heavy and hard construction, dry motor type with interposition of the oil chamber between the hydraulic part and the motor side. CONSTRUCTION DATA Impeller type Double channel Free passage (mm) 80 Discharge diameter (mm) DN 100 Suction (mm) DN 125 Cooling By surrounding fluid Motor type M410T-4,6-400/50YY-IE3 - (Watertight, suitable for VFD) Mechanical prot. Degree IP 68 Rated motor power (kW) 4,6 Rated current (A) 9,3 Starting type Direct - Star/Delta Starting Supply 3ph 400/690V-50Hz Nominal speed (rpm) 1401 Winding insulation Class H Duty service S1 Continuous Electric cable N-Neoprene submersible, length 10 m Shaft seal Double Liquid max. temperature (°C) < 40 Pump protection Motor Thermal Protections - Leakage Sensor in oil chamber Surface painting Epoxy painting MATERIALS Diffuser Cast Iron EN-GJL-250 Shaft Stainless Steel AISI 420B Impeller Cast Iron EN-GJL-250+Ni Upper seal Ceramic/Graphite Lower seal Silicon Carbide/Silicon Carbide Screws A2 Class AISI 304 O-Rings Nitrile Ball bearings Ball bearings life lubricated

Please Contact Us to Order to offer competitive prices and delivery time for Faggiolati - G410R2C2-P80AA2 pump number, also you may ask some other model number is well. We can offer competitive price, and delivery time with wide products distribution network in United Kingdom Industrial products Market.

WE SELL ONLY NEW AND ORIGINAL PRODUCTS!

Our company is not an authorized distributor. All rights are reserved by the manufacturers and their official partners.
