BRAND | Faggiolati |
Product | G416R2C2-S100KA2 |
Internal code | 4819733 |
Technical specification | Impeller type Double channel Free passage (mm) 100 Discharge diameter (mm) DN 150 Suction (mm) DN 150 Cooling By Surrounding Fluid Engine type M416T-27-400/50YY-IE3 - (Watertight) Mechanical prot. Degree IP 68 Rated motor power (kW) 27.0 Rated current (A) 49.6 Starting type Direct - Star/Delta Starting Supply 3ph 400/690V-50Hz Nominal speed (rpm) 1441 Winding insulation Class H Duty Service S1 Continuous Electric cable N-Neoprene submersible, length 10 m Double Mechanical Shaft Seal Liquid max. temperature (°C) < 40 Pump protection Motor Thermal Protections - Leakage Sensor in oil chamber Surface painting Epoxy painting MATERIALS Cast Iron EN-GJL-250 Diffuser AISI 431 Stainless Steel Shaft Impeller Stainless Steel AISI 316L Upper seal Ceramic/Graphite Lower seal Silicon Carbide/Silicon Carbide Screws A4 Class AISI 316 Nitrile O-Rings MATERIALS Ball bearings Ball bearings life lubricated Motor Casing Rated current (A) 49.6 CONSTRUCTION DATA Required duty Cast Iron EN-GJL-250 |
Please Contact Us to Order to offer competitive prices and delivery time for Faggiolati - G416R2C2-S100KA2 number, also you may ask some other model number is well. We can offer competitive price, and delivery time with wide products distribution network in United Kingdom Industrial products Market.
WE SELL ONLY NEW AND ORIGINAL PRODUCTS!
Our company is not an authorized distributor. All rights are reserved by the manufacturers and their official partners.
